DC-Link DPB Capacitor 1200V
Metallized polypropylene film structure
Excellent electric property
Plastic case (UL94v-0), filled with resin
High performance DC filtering applications(i.e.transducers,industrial and high-end power supplies and solar inverters)
- Product Introduction
Features
- Metallized polypropylene film structure
- Excellent electric property
- Plastic case (UL94v-0), filled with resin
- High performance DC filtering applications(i.e.transducers, industrial and high-end power supplies and solar inverters)
|
SPECIFICATIONS |
|
|
Climatic Category |
40/85/56 |
|
Rated Voltage |
500V, 600V, 800V, 1000V, 1100V, 1200V |
|
Capacitance Range |
0.00022μF ~3.9μF |
|
Capacitance Tolerance |
±5%(J), ±10%(K) |
|
Voltage Proof |
1.5UR |
|
Insulation resistance |
≥10000S (20℃, 1KHZ) |
DRAWING: (mm)
Advantage
- Industrial inverter optimization: improve inverter efficiency and stability.
- Energy storage system support: optimize charging and discharging efficiency, extend battery life
- High-frequency resonant circuits: suitable for high-precision scenarios such as LLC, wireless charging, etc.
- Maintenance-free design: no need for replacement or maintenance during the whole life cycle
- Cost-effective: lower overall cost than electrolytic capacitor + buffer circuit solutions
- Modular integration: supports customized parallel/series modules to simplify system design
- Fast response to market: compatible with mainstream brand replacement needs, shorten development cycle
- RoHS/REACH compliant: no hazardous substances, green and environmentally friendly.
Application Scenario
- Induction furnace and induction heating equipment: energy storage and release of high-frequency resonant circuit.
- Industrial robots: Suppress high-frequency harmonic interference in servo systems.
- Power active filter (APF): Improve the power quality of the grid and filter out harmonics.
- Air conditioner inverter drive: Improve efficiency and reliability of compressor drive circuit.
- Solar street light controller: Stabilizes the DC voltage input from solar panels.
- Wireless charging equipment: for energy storage and energy transmission in high frequency resonant circuits.
- High-end audio power supply: filter out power supply noise and enhance sound purity.
FAQ
ZZEC Corporate Profile
Was established in 2007, the company is located in Yue yang city of Hunan province Yue yang county Bai Xiang town industrial zone, the enterprise from the beginning of entrepreneurship, "the spirit of customer first, forge ahead" spirit, focus on satisfy clients' demand for miniaturization, from at home and abroad to introduce advanced machines, to form a number of automated production line, at the same time subminiature automatic assembling machine imported from Italy, Specializing in the production of MINI BOX capacitor (super small BOX potting capacitor) and super small size, high precision series capacitor. To achieve annual shipments of about 2 billion film capacitors. Product quality is the survival foundation of the enterprise, relying on ISO9001 quality system, we use high-quality raw materials and high reliability of the process, thick accumulation to provide more than 300 agents and 1500 final customers with stable and reliable products and customized services. Step by step to develop into an influential enterprise in the industry
ZZEC Company Photo
1. Self-developed
2. Free samples
3. Can be customized according to customer needs
4. Standard dust-free workshop
5. Advanced laboratory and equipment
6. Can provide the data of the sample production stage
Workshop Pictures
Specializing in ultra-small, high-precision, high-quality film capacitors.
